Single layer non insulation glass

Single layer non insulation glass is a kind of curtain wall or door and window glass for building exterior with fireproof function. It is obtained by treating float glass with physical and chemical methods. It can keep 30-120 minutes without blowing up in 1000℃ flame, thus effectively stopping the spread of flame and smoke, so that people have long enough time to evacuate the scene and carry out disaster relief work. Its appearance solves the fatal weakness of poor fire safety of ordinary glass facade, and greatly improves the safety coefficient of glass facade.

Technical Data

Single Layer non insulation Glass
Glass Range	Glass Type	Thickness (mm)	Integrity (mins)	Insulation (mins)	Weight (KG/SQ)	Fire Proof Temperature (℃)
E-Fireproof Glass	Single Layer non insulation Glass	5	30、60、90	—	12.5	≥1000
		6	30、60、90	—	15	≥1000
		8	30、60、90	—	20	≥1000
		10	30、60、90、120	—	25	≥1000
		12	30、60、90、120	—	30	≥1000
		15	30、60、90	—	37.5	≥1000
		19	30、60、90	—	47.5	≥1000

Product Performance Characteristics

1. Fireproof performance
High-stress monolithic fireproof glass has strong fireproof performance, in its fire-resistant time limit can maintain the integrity and not broken, can block the flame, smoke and combustion generated by the proliferation of high-temperature gas diffusion and spread.
2. High strength
High-strength monolithic fireproof glass is 6-12 times that of ordinary float glass of the same thickness and 1.5-3 times that of tempered glass. Therefore, under the same wind pressure, it can be designed with thinner thickness or larger area, which increases the sense of transparency and reduces the cost.
3. Deep processing
It can be processed into hollow fireproof, laminated fireproof, curtain wall fireproof glass, coated fireproof glass and so on.
4. Safety
Maintain integrity within the fire-resistant time limit; when exceeding the fire-resistant time limit, the glass softens; when broken by external impact, the particles are small and do not hurt people.
5. Anti-aging
Resistant to heat, cold, humidity and light.
6. Easy to install
Lightweight for transportation, handling and installation.

Application Field

Exterior curtain walls, building facades, non-insulated fire rated glass doors, smoke walls, light roofs, furnace front windows.
